Industrial Smart Pressure Transmitter, Gauge Pressure

Strong transient voltage resistance to protect the terminal module
Dual diaphragm overload structure can easily cope with high overload tests
Accurate filling fluid technology eliminates the effects of temperature and static pressure
High-strength metal electrical protection housing meets the most rigorous environmental application

Responsive after-sales service / Customizable /
High quality / One-year warranty
The image is for reference; the actual product willbe based on your custom specifications.

Description

This absolute pressure transmitter features a high-precision monosilicon sensor with a dual-diaphragm overload protection design, ensuring excellent stability and durability under high pressure. The 355° rotatable display module and intuitive button interface allow easy parameter adjustment and monitoring. Its high-strength metal housing provides superior protection against impact and corrosion, ideal for demanding industrial environments. Certified by Ex, IEC, CE, RoHS, and HART

Specifications

Scale ranges	2 kPa ... 40 MPa
Output signal	4-20mA, 4-20mA/HART
Accuracy	±0.1% URL (standard), ±0.075% URL
Stability	±0.2% URL/ 5 years
Diaphragm	SUS 316L, Hastelloy
Medium temperature	-20℃ ... 85℃, integrated LCD display -20℃ ... 70℃
Accuracy	±0.1% URL (standard), ±0.075% URL
IP rating	IP 67
Process connection	M20 x 1.5 (M), G1/2(M), G1/4(M) 1/2", 1/4" NPT(M) 1/2", 1/4" NPT (F)
Approvals	CSA, ATEX, IECEx, NEPSI, RoHS, CE
