Threaded Connection, Bottom PP

Threaded Connection, Bottom PP

Model: DIT-PPS
  • Could be integrated with a pointer, digital manometer or transmitter
  • Suitable for measuring acidic fluids, which are compatible with Viton
  • Suitable for circuit board equipment, the petrochemical industry, etc.
  • Servicio posventa reactivo / Personalizable /
  • Alta calidad / Un año de garantía
  • La imagen es de referencia; el producto real se basará en sus especificaciones personalizadas.
Solicitar presupuesto

Descripción

The DIT-PPS bottom-mounted polypropylene diaphragm seal is designed for measuring acidic or corrosive fluids and can be paired with mechanical gauges, digital manometers, or pressure transmitters. With a pressure range from 0 to 20 bar, its black PP body and Viton diaphragm provide strong chemical resistance and durability. It is ideal for PCB processing equipment, chemical dosing systems, liquid filtration systems, and other applications requiring lightweight and corrosion-resistant pressure measurement.

Especificaciones

Scale ranges Pressure gauge:
0 ... 1 bar to 0 ... 20 bar, or all other equivalent pressure ranges
Digital pressure gauge and pressure transmitter:
0 ... 1 bar to 0 ... 20 bar, or all other equivalent vacuum or combined pressure and vacuum ranges
Process connection 1/2PT (female)
Instrument connection G 1/4
Material Body: Polypropylene, black
Diaphragm: Viton
Medium temperature 0℃ ... 60℃

Descargas

Inglés

SJ-Gauge-DIT-PPS-diaphragm-seals-datasheet-en.pdf
SJ-Gauge-DIT-PPS-diaphragm-seals-datasheet-zh-tw.pdf
