工業級智慧型壓力變送器、錶壓
- Strong transient voltage resistance to protect the terminal module
- Dual diaphragm overload structure can easily cope with high overload tests
- Accurate filling fluid technology eliminates the effects of temperature and static pressure
- High-strength metal electrical protection housing meets the most rigorous environmental application
- 反應迅速的售後服務 / 可客製化 / 可依客戶需求提供服務
- 高品質 / 一年保固
- 圖片僅供參考；實際產品將根據您的自訂規格製作。.
說明
This absolute pressure transmitter features a high-precision monosilicon sensor with a dual-diaphragm overload protection design, ensuring excellent stability and durability under high pressure. The 355° rotatable display module and intuitive button interface allow easy parameter adjustment and monitoring. Its high-strength metal housing provides superior protection against impact and corrosion, ideal for demanding industrial environments. Certified by Ex, IEC, CE, RoHS, and HART
規格
| 刻度範圍 | 2 kPa ... 40 MPa |
|---|---|
| 輸出信號 | 4-20mA, 4-20mA/HART |
| 精確度 | ±0.1% URL (standard), ±0.075% URL |
| 穩定性 | ±0.2% URL/ 5 年 |
| 隔膜 | SUS 316L, Hastelloy |
| 中溫 | -20℃ ... 85℃, integrated LCD display -20℃ ... 70℃ |
| 精確度 | ±0.1% URL (standard), ±0.075% URL |
| IP 等級 | IP 67 |
| 製程連線 | M20 x 1.5 (M), G1/2(M), G1/4(M) 1/2", 1/4" NPT(M) 1/2", 1/4" NPT (F) |
| 認證 | CSA, ATEX, IECEx, NEPSI, RoHS, CE |
產品圖片
